Those red, white, and yellow cables that came with your VCR have a name: RCA cables. They've been the standard way to connect video equipment for decades.
The Standard Color Code
Yellow = Composite Video - Carries the complete video signal (picture)
White = Left Audio (or Mono) - Carries left channel of stereo audio
Red = Right Audio - Carries right channel of stereo audio
This color coding is universal. Yellow always goes to yellow, white to white, red to red.
Types of Video Connections
Composite Video (Yellow)
Composite combines all video information into one cable. It's the most basic video connection and works with any TV that has RCA inputs. For VHS playback, composite is perfectly adequate since VHS resolution is relatively low.
Component Video (Red, Green, Blue)
Component splits the video signal into three cables for better quality. The colors are Green (Y), Blue (Pb), and Red (Pr). This offers better picture quality than composite, especially for DVD playback.
Important: Don't confuse the red component video cable with the red audio cable.
Connecting Your VCR
1. Locate yellow, white, and red outputs on VCR back
2. Find matching inputs on your TV
3. Connect yellow to yellow (video)
4. Connect white to white (left audio)
5. Connect red to red (right audio)
6. Set TV to correct input (AV, Video, or Composite)
If Your TV Has No RCA Inputs
Modern TVs often have only HDMI. You need an RCA-to-HDMI converter—a small box that converts analog signals to digital HDMI. These cost $15-30 and require USB power.
Troubleshooting
• **No picture, no sound:** Check all cables are firm, verify TV input
• **Picture but no sound:** Check both audio cables are connected
• **Sound but no picture:** Check yellow video cable
• **Wrong colors:** Make sure you're using composite, not component
